80amp Energy Storage Sytem Fuses Semiconductor Fuse Made In China Power Fuse

Name: 80amp Energy Storage Sytem Fuses Semiconductor Fuse Made In China Power Fuse
Brand: Dissmann
Price: 1 USD

Quality 80amp Energy Storage Sytem Fuses Semiconductor Fuse Made In China Power Fuse wholesale

Brand Name : Dissmann

Model Number : MEV-P-C30

Certification : UL

Place of Origin : China

MOQ : 100pcs

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 1,000,000pcs

Delivery Time : 5-8days

Packaging Details : Standard Carton Packing

Material : Ceramic

Color : White

Rated Voltage : 250VDC

Rated Current : 80A

Breaking Capacity : DC50KA

Meet the requirements : IEC60269、JASO-D622、UL248、RoHS

Installation : Available in Bolt

Application : Solar inverter,EV car battery,Automobile

Contact Now

750 VDC EV Battery Fuse Equivalent to Bussmann

1.Application of the EV battery fuse

This electric vehicle battery fuse is suitable for rated voltage of 750Vdc,rated current range of 10A-400A. As a comprehensive protection for vehicle battery,vehicle wiring system and inverter,and the rated breaking capacity up to 50KA.The fuses dimension and performance conform to IEC60269,JASO-D622,UL248,RoHS of international electric vehicle industry.

2.Product characteristic of 750VDC EV fuse

Model

Rated Current

Installation

MEV-H-F00-315

315A

Mounting bolt M8 recommended torque 10N.m

3.Product type of the 750VDC EV series fuse

Model	Product code	Rated current	I²t(A²Sec)		Power consumption
MEV-P-C10	MEV-P-C10-16	16	7.2	48	5.5
	MEV-P-C10-20	20	11.5	78	7
	MEV-P-C10-25	25	19	130	9
	MEV-P-C10-32	32	40	270	10
	MEV-P-C10-40	40	69	460	12
	MEV-P-C10-50	50	115	770	15
	MEV-P-C10-63	63	215	1450	16
	MEV-P-C10-80	80	380	2550	19
	MEV-P-C10-100	100	695	4650	24
	MEV-P-C10-125	125	1200	8500	28
	MEV-P-C10-160	160	2300	16000	32
	MEV-P-C10-200	200	4200	28000	37
	MEV-P-C10-250	250	7750	51500	42
	MEV-P-C10-315	315	12000	80500	52
	MEV-P-C10-350	350	14500	98500	58
	MEV-P-C10-400	400	19500	133000	67
MEV-P-C20	MEV-P-C20-16	16	7.2	48	5.5
	MEV-P-C20-20	20	11.5	78	7
	MEV-P-C20-25	25	19	130	9
	MEV-P-C20-32	32	40	270	10
	MEV-P-C20-40	40	69	460	12
	MEV-P-C20-50	50	115	770	15
	MEV-P-C20-63	63	215	1450	16
	MEV-P-C20-80	80	380	2550	19
	MEV-P-C20-100	100	695	4650	24
	MEV-P-C20-125	125	1200	8500	28
	MEV-P-C20-160	160	2300	16000	32
	MEV-P-C20-200	200	4200	28000	37
	MEV-P-C20-250	250	7750	51500	42
	MEV-P-C20-315	315	12000	80500	52
	MEV-P-C20-350	350	14500	98500	58
	MEV-P-C20-400	400	19500	133000	67
MEV-P-C30	MEV-P-C30-16	16	7.2	48	5.5
	MEV-P-C30-20	20	11.5	78	7
	MEV-P-C30-25	25	19	130	9
	MEV-P-C30-32	32	40	270	10
	MEV-P-C30-40	40	69	460	12
	MEV-P-C30-50	50	115	770	15
	MEV-P-C30-63	63	215	1450	16
	MEV-P-C30-80	80	380	2550	19
	MEV-P-C30-100	100	695	4650	24
	MEV-P-C30-125	125	1200	8500	28
	MEV-P-C30-160	160	2300	16000	32
	MEV-P-C30-200	200	4200	28000	37
	MEV-P-C30-250	250	7750	51500	42
	MEV-P-C30-315	315	12000	80500	52
	MEV-P-C30-350	350	14500	98500	58
	MEV-P-C20-400	400	19500	133000	67

4.Product dimension of 750v car battery fuse

80amp Energy Storage Sytem Fuses Semiconductor Fuse Made In China Power Fuse

FAQ

Question:1.Are fuses also uesd in foreign-made automobiles?

The fuse is used by automakers around the world. Automatic fuse, mini fuse and low -key fuses are under international standards and used in vehicles around the world. Our automatic fuse, mini fuse and configuration fuse are used in vehicles made in Japan and South Korea and other parts of Asia.
