DC30KA Ceramic Automotive Fuses 1000VDC suitable for EV Charger

Name: DC30KA Ceramic Automotive Fuses 1000VDC suitable for EV Charger
Brand: Dissmann
Price: 1 USD

Quality DC30KA Ceramic Automotive Fuses 1000VDC suitable for EV Charger wholesale

Brand Name : Dissmann

Model Number : HEV-J-Q

Certification : TUV/CCC

Place of Origin : China

MOQ : 100pcs

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 1,000,000pcs

Delivery Time : 5-8days

Packaging Details : Standard Carton Packing

Material : Ceramic

Color : White

Rated Current : 5A-800A

Rated Voltage : AC/DC1000V

Interrupting Rating : DC30KA@DC1000V

Type of protection : aR

Contact Now

Ceramic EV Charger fuse designed for electric vehicle charging pile

Application for EV charger

This series fuse are rated 1000 volts with ampere ratings from 5 to 800 amps. These types of fuses are used extensively in cars, trucks, buses and off-road transportation equipment to protect the cables, wires and electrical components that supply electrical power to operate lights, heaters, air conditioning, radios, power windows and other electrical accessories. They are also used in electric and hybrid vehicles and a variety of electronic applications.

Feature data

Model

Rated Current(A)

100% voltage drop (mv)

Size code

Installation

HEV-J-Q-300

300

298

HF3

Mounting Bolt M10,

Recommend Torque: 21N.m

Product dimension of the HEV fuse

DC30KA Ceramic Automotive Fuses 1000VDC suitable for EV Charger

Size code	A±2	B±1.5	C±1	D±1.5	E±1.5	F±1	G±0.5	H±0.2	J±1
HF3	139.5	38	83.5	99.5	120	10.5	25	6	20.7

Material of the EV charger fuse

Part	Material
Fuse wire	Copper or Silver
End cap	Copper alloy tin plating
Fuse leg	Copper alloy tin plating
Fuse body	Ceramic Tube
Filler	Quartz sand

Packaging Quantity

HF4: 2 fuse links per plastic box.

Each long box is packed with 1 plastic box, a total of 2 fuse links, the size of the long box is 156mm long x 120mm wide x 54mm high.

Each large box contains 20 long strip boxes, a total of 40 fuse links, the size of the large box is 342mm long x 258mm wide x 285mm high.

FAQ:

Question 1:What is your fuse test condition?

Answer 1:Our fuse is tested under the condition of 25 ± 5 ° C in the laboratory.
