UL 400 Amp Dc Fuse , White AR Protection European Square Fuse

Name: UL 400 Amp Dc Fuse White AR Protection European Square Fuse
Brand: Dissmann
Price: 1 USD

Quality UL 400 Amp Dc Fuse , White AR Protection European Square Fuse wholesale

Brand Name : Dissmann

Model Number : MEV-P-C10

Certification : UR,UL

Place of Origin : China

MOQ : 100pcs

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 1,000,000pcs

Delivery Time : 5-8days

Packaging Details : Standard Carton Packing

Material : Ceramic tube

Colour : White

Rated Current : 400A

Rated Voltage : 750VDC

Interrupting Capacity : DC10KA/AC20KA

Certificates : UR,UL

Protection type : aR

Contact Now

Automotive Electricle Fuses European Square Fuse 750volt DC Fuse

Material:
Noumenon: Ceramic
Pins: Copper alloy

Product Presentation:

Rated Voltage

额定电压

DC750V,AC690V

或低于

Type Protection

保护类别

Rated Current 额定电流

10A-400A

Breaking Capacity

分断能力

DC10KA

(时间常数≤10ms)

Meet the Requirement

符合要求

UL248-13,ISO8820,JASO-D622,IEC60269

欧盟和RoHS 指令

Remarks

备注

产品外形尺寸(mm)/Overall dimensions of the product(mm)

UL 400 Amp Dc Fuse , White AR Protection European Square Fuse

MEV-P-C10 MEV-P-C20 MEV-P-C30

电流特性曲线图/Current characteristic curve

UL 400 Amp Dc Fuse , White AR Protection European Square Fuse

产品型号/Product type

Model 型号	Product code 产品代码	Rated current 额定电流 A	I²t(A²Sec)		Power consumption 功率损耗 W
Model 型号	Product code 产品代码	Rated current 额定电流 A	弧前	总	Power consumption 功率损耗 W
MEV-P-C10	MEV-P-C10-16	16	7.2	48	5.5
	MEV-P-C10-20	20	11.5	78	7
	MEV-P-C10-25	25	19	130	9
	MEV-P-C10-32	32	40	270	10
	MEV-P-C10-40	40	69	460	12
	MEV-P-C10-50	50	115	770	15
	MEV-P-C10-63	63	215	1450	16
	MEV-P-C10-80	80	380	2550	19
	MEV-P-C10-100	100	695	4650	24
	MEV-P-C10-125	125	1200	8500	28
	MEV-P-C10-160	160	2300	16000	32
	MEV-P-C10-200	200	4200	28000	37
	MEV-P-C10-250	250	7750	51500	42
	MEV-P-C10-315	315	12000	80500	52
	MEV-P-C10-350	350	14500	98500	58
	MEV-P-C10-400	400	19500	133000	67
MEV-P-C20	MEV-P-C20-16	16	7.2	48	5.5
	MEV-P-C20-20	20	11.5	78	7
	MEV-P-C20-25	25	19	130	9
	MEV-P-C20-32	32	40	270	10
	MEV-P-C20-40	40	69	460	12
	MEV-P-C20-50	50	115	770	15
	MEV-P-C20-63	63	215	1450	16
	MEV-P-C20-80	80	380	2550	19
	MEV-P-C20-100	100	695	4650	24
	MEV-P-C20-125	125	1200	8500	28
	MEV-P-C20-160	160	2300	16000	32
	MEV-P-C20-200	200	4200	28000	37
	MEV-P-C20-250	250	7750	51500	42
	MEV-P-C20-315	315	12000	80500	52
	MEV-P-C20-350	350	14500	98500	58
	MEV-P-C20-400	400	19500	133000	67
MEV-P-C30	MEV-P-C30-16	16	7.2	48	5.5
	MEV-P-C30-20	20	11.5	78	7
	MEV-P-C30-25	25	19	130	9
	MEV-P-C30-32	32	40	270	10
	MEV-P-C30-40	40	69	460	12
	MEV-P-C30-50	50	115	770	15
	MEV-P-C30-63	63	215	1450	16
	MEV-P-C30-80	80	380	2550	19
	MEV-P-C30-100	100	695	4650	24
	MEV-P-C30-125	125	1200	8500	28
	MEV-P-C30-160	160	2300	16000	32
	MEV-P-C30-200	200	4200	28000	37
	MEV-P-C30-250	250	7750	51500	42
	MEV-P-C30-315	315	12000	80500	52
	MEV-P-C30-350	350	14500	98500	58
	MEV-P-C20-400	400	19500	133000	67

Product Anatomy

Product Applications

UL 400 Amp Dc Fuse , White AR Protection European Square Fuse

Test Equipment

Production Equipment

Our Certificates
